Unipolar/Bipolar System
Our Unipolar/Bipolar System offers versatile electrosurgical capability in a single, compact platform. Combining both unipolar (monopolar) and bipolar modes, it provides surgeons with maximum flexibility for a wide range of procedures.
Key Features
- Dual-Mode Operation — Seamless switching between unipolar and bipolar modes
- Advanced Waveform Control — Multiple cutting and coagulation waveforms
- Contact Quality Monitoring — Real-time return electrode monitoring for patient safety
- Intuitive Interface — Large display with preset and custom mode settings
- Compact Design — Space-saving footprint for operating room efficiency
- Modular Architecture — Easy integration with existing OR systems
Specifications
| Parameter | Specification |
|---|---|
| Output Power | 400W (unipolar) / 120W (bipolar) |
| Unipolar Modes | Cut, Blend 1-3, Coagulate |
| Bipolar Modes | Standard, Macro, Micro |
| Frequency | 400 kHz - 1.7 MHz |
| Display | Color LCD with waveform visualization |
| Return Electrode Monitoring | CQM (Contact Quality Monitoring) |
| Safety Features | Over-current, over-voltage, arc detection |
Applications
- General surgery
- Plastic and reconstructive surgery
- ENT surgery
- Urology
- Gynecology
- Dermatology
Ordering Information
Contact us for pricing, bulk orders, and OEM customization options.
